Rigol has developed a complete line of digital oscilloscopes to help you achieve faster debugging and testing of your newest designs. Compare our powerful functions and compact designs to your current scope and you'll see we offer state-of-the-art technology. Compare the prices and you'll be surprised how much you can save.
Product | Analog Channels | Digital Channels | Bandwidth | Waveform Capture Rate | Standard Memory | Real-time Sampling Rate | Price (THB) | |
---|---|---|---|---|---|---|---|---|
MSO1104Z-S | 4 | 16 | 100 MHz | 30,000 wfms/s | 12 Mpoints | 1GSa/s | - | |
MSO1104Z | 4 | 16 | 100 MHz | 30,000 wfms/s | 12 Mpoints | 1GSa/s | - | |
DS1104Z-S | 4 | 100 MHz | 30,000 wfms/s | 12 Mpoints | 1GSa/s | - | ||
DS1104Z | 4 | 100 MHz | 30,000 wfms/s | 12 Mpoints | 1GSa/s | - | ||
DS1054Z | 4 | 50 MHz | 30,000 wfms/s | 12 Mpoints | 1GSa/s | - | ||
DS1204B | 4 | 200 MHz | 16 kpoints | 2GSa/s | - | |||
DS1104B | 4 | 100 MHz | 16 kpoints | 2GSa/s | - | |||
DS1102E | 2 | 100 MHz | 1 Mpoints | 1GSa/s | - | |||
DS1102D | 2 | 16 | 100 MHz | 1 Mpoints | 1GSa/s | - | ||
DS1074B | 4 | 70 MHz | 16 kpoints | 2GSa/s | - | |||
MSO4054 | 4 | 16 | 500 MHz | 110,000 wfms/s | 140 Mpoints | 4GSa/s | - | |
MSO4052 | 2 | 16 | 500 MHz | 110,000 wfms/s | 140 Mpoints | 4GSa/s | - | |
MSO4034 | 4 | 16 | 350 MHz | 110,000 wfms/s | 140 Mpoints | 4GSa/s | - | |
MSO4032 | 2 | 16 | 350 MHz | 110,000 wfms/s | 140 Mpoints | 4GSa/s | - | |
MSO4024 | 4 | 16 | 200 MHz | 110,000 wfms/s | 140 Mpoints | 4GSa/s | - | |
MSO4022 | 2 | 16 | 200 MHz | 110,000 wfms/s | 140 Mpoints | 4GSa/s | - | |
MSO4014 | 4 | 16 | 100 MHz | 110,000 wfms/s | 140 Mpoints | 4GSa/s | - | |
MSO4012 | 2 | 16 | 100 MHz | 110,000 wfms/s | 140 Mpoints | 4GSa/s | - | |
DS4054 | 4 | 500 MHz | 110,000 wfms/s | 140 Mpoints | 4GSa/s | - | ||
DS4052 | 2 | 500 MHz | 110,000 wfms/s | 140 Mpoints | 4GSa/s | - | ||
DS4034 | 4 | 350 MHz | 110,000 wfms/s | 140 Mpoints | 4GSa/s | - | ||
DS4032 | 2 | 350 MHz | 110,000 wfms/s | 140 Mpoints | 4GSa/s | - | ||
DS4024E | 4 | 200 MHz | 60,000 wfms/s | 14 Mpoints | 2GSa/s | - | ||
DS4024 | 4 | 200 MHz | 110,000 wfms/s | 140 Mpoints | 4GSa/s | - | ||
DS4022 | 2 | 200 MHz | 110,000 wfms/s | 140 Mpoints | 4GSa/s | - | ||
DS4014E | 4 | 100 MHz | 60,000 wfms/s | 14 Mpoints | 2GSa/s | - | ||
DS4014 | 4 | 100 MHz | 110,000 wfms/s | 140 Mpoints | 4GSa/s | - | ||
DS4012 | 2 | 100 MHz | 110,000 wfms/s | 140 Mpoints | 4GSa/s | - | ||
MSO2302A-S | 2 | 16 | 300 MHz | 50,000 wfms/s | 14 Mpoints | 2GSa/s | - | |
MSO2302A | 2 | 16 | 300 MHz | 50,000 wfms/s | 14 Mpoints | 2GSa/s | - | |
MSO2202A-S | 2 | 16 | 200 MHz | 50,000 wfms/s | 14 Mpoints | 2GSa/s | - | |
MSO2202A | 2 | 16 | 200 MHz | 50,000 wfms/s | 14 Mpoints | 2GSa/s | - | |
MSO2102A-S | 2 | 16 | 100 MHz | 50,000 wfms/s | 14 Mpoints | 2GSa/s | - | |
MSO2102A | 2 | 16 | 100 MHz | 50,000 wfms/s | 14 Mpoints | 2GSa/s | - | |
MSO2072A-S | 2 | 16 | 70 MHz | 50,000 wfms/s | 14 Mpoints | 2GSa/s | - | |
MSO2072A | 2 | 16 | 70 MHz | 50,000 wfms/s | 14 Mpoints | 2GSa/s | - | |
DS2302A-S | 2 | 300 MHz | 50,000 wfms/s | 14 Mpoints | 2GSa/s | - | ||
DS2302A | 2 | 300 MHz | 50,000 wfms/s | 14 Mpoints | 2GSa/s | - | ||
DS2202A-S | 2 | 200 MHz | 50,000 wfms/s | 14 Mpoints | 2GSa/s | - | ||
DS2202A | 2 | 200 MHz | 50,000 wfms/s | 14 Mpoints | 2GSa/s | - | ||
DS2102A-S | 2 | 100 MHz | 50,000 wfms/s | 14 Mpoints | 2GSa/s | - | ||
DS2102A | 2 | 100 MHz | 50,000 wfms/s | 14 Mpoints | 2GSa/s | - | ||
DS2072A-S | 2 | 70 MHz | 50,000 wfms/s | 14 Mpoints | 2GSa/s | - | ||
DS2072A | 2 | 70 MHz | 50,000 wfms/s | 14 Mpoints | 2GSa/s | - | ||
DS6104 | 4 | 1 GHz | 180,000 wfms/s | 140 Mpoints | 5GSa/s | - | ||
DS6102 | 2 | 1 GHz | 180,000 wfms/s | 140 Mpoints | 5GSa/s | - | ||
DS6064 | 4 | 600 MHz | 180,000 wfms/s | 140 Mpoints | 5GSa/s | - | ||
DS6062 | 2 | 600 MHz | 180,000 wfms/s | 140 Mpoints | 5GSa/s | - | ||
DS2202E | 2 | 200MHz | 50,000 wfms/s | 28 Mpoints / CH | 1GSa/s per CH | - | ||
DS2102E | 2 | 100MHz | 50,000 wfms/s | 28 Mpoints / CH | 1GSa/s per CH | - | ||
MSO7054 | 4 | 16 | 500MHz | 600,000 wfms/s | 100 Mpts | 10 GSa/s | - | |
MSO7034 | 4 | 16 | 350MHz | 600,000 wfms/s | 100 Mpts | 10 GSa/s | - | |
MSO7024 | 4 | 16 | 200MHz | 600,000 wfms/s | 100 Mpts | 10 GSa/s | - | |
MSO7014 | 4 | 16 | 100MHz | 600,000 wfms/s | 100 Mpts | 10 GSa/s | - | |
DS7054 | 4 | 500MHz | 600,000 wfms/s | 100 Mpts | 10 GSa/s | - | ||
DS7034 | 4 | 350MHz | 600,000 wfms/s | 100 Mpts | 10 GSa/s | - | ||
DS7024 | 4 | 200MHz | 600,000 wfms/s | 100 Mpts | 10 GSa/s | - | ||
DS7014 | 4 | 100MHz | 600,000 wfms/s | 100 Mpts | 10 GSa/s | - | ||
MSO5354 | 4 | 16 (opt) | 350MHz | 500,000 wfms/s | 100 Mpts (200M opt) | 8GSa/s Max. | - | |
MSO5204 | 4 | 16 (opt) | 200MHz | 500,000 wfms/s | 100 Mpts (200M opt) | 8GSa/s Max. | - | |
MSO5104 | 4 | 16 (opt) | 100MHz | 500,000 wfms/s | 100 Mpts (200M opt) | 8GSa/s Max. | - | |
MSO5074 | 4 | 16 (opt) | 70MHz | 500,000 wfms/s | 100 Mpts (200M opt) | 8GSa/s Max. | - |
